USE AND MAINTENANCE MANUAL
REFRIGERATED CABINETS PERFEKT | PERFEKT PLUS
21
EN
3.4.1. REFRIGERATING UNIT
The built-in refrigerating unit consists of:
▪ compressor
▪ air condenser
▪ evaporator
▪ condenser fan
▪ evaporator fan
▪ defrosting resistance on BT version evaporator
▪ condensate water automatic evaporation
3.4.2. OPTIONAL - REMOTE SET-UP MONOBLOCK UNIT
The monoblock unit with remote set-up is composed of:
▪ evaporator
▪ evaporator fan
▪ condensate water discharge siphon
In the BT and PLUS version, the evaporator is equipped with a
defrosting resistance.
The remote unit must be placed away from atmospheric agents,
avoiding using the site where it is installed as a deposit for
materials that would prevent correct air circulation.
Depending on the characteristics of the remote condenser unit
model, the spaces from the wall or other obstacles must be
respected so that there is a sufficiently adequate air exchange
that ensures correct operation of the refrigerator cabinet and
easy maintenance.
condensate
drain
