13
Fig. 4.1
Fig. 4.2
IMPORTANT
– The appliance should be installed by a
QUALIFIED INSTALLATION TECHNICIAN.
The appliance must be installed in com-
pliance with regulations in force.
Installation
44
The oven can be fitted in standard units,
width and depth 60 cm.
Installation requires a compartment as
illustrated in figures 4.1 and 4.2.
On the lower side, the oven must lay on
supports standing the oven weight.
Using 4 screws (not supplied) the oven
can be secured to the oven housing.
It is necessary that the furniture module
provides for a ventilation column, as
shown on picture.
