2-6

2-1-5 Typical Wiring for Motor and Main Circuit

* The Wiring Example of Single Phase Main Power (Less than 1KW)

* The Wiring Example of 3 Phase Main Power (More than 1KW)

3 Phase 220V

TB1

NFB

Red

White

Black

Green

External

Regeneration

BK Resistance

Power ON

Power OFF

Power Filter

MC/R

MC/S

MC/T

MC/a

CN2
