TECO 7300CV User Manual

7300CV MODBUS COMMUNICATION PROTOCOL
File No. :PC-CV-08
Version : 1.A
Page :
6/34
3.Command START ADDRESS
Function Description
Command
Start Address
Data length
(WORD)
Ladder page1 read 200H 0AH
Ladder page2 read 20AH 0AH
Ladder page3 read 214H 0AH
Ladder page4 read 21EH 0AH
Ladder page5 read 228H 0AH
Timer1 Function read 264H 05H
Timer2 Function read 269H 05H
Timer3 Function read 26EH 05H
Timer4 Function read 273H 05H
Timer5 Function read 278H 05H
Timer6 Function read 27DH 05H
Timer7 Function read 282H 05H
Timer8 Function read 287H 05H
Counter1 Function read 28CH 04H
Counter2 Function read 290H 04H
Counter3 Function read 294H 04H
Counter4 Function read 298H 04H
Encoder1 Function read 2ACH 05H
Encoder2 Function read 2B1H 05H
Encoder3 Function read 2B6H 05H
Encoder4 Function read 2BBH 05H
Analog1 Function read 2C0H 03H
Analog2 Function read 2C3H 03H
Analog3 Function read 2C6H 03H
Analog4 Function read 2C9H 03H
Control function read 2CCH 06H
Contro2 function read 2D2H 06H
Contro3 function read 2D8H 06H
Contro4 function read 2DEH 06H
Contro5 function read 2E4H 06H
Contro6 function read 2EAH 06H
Contro7 function read 2F0H 06H
Contro8 function read 2F6H 06H
03
All Coil status read 2FCH~303H 08H

TECO 7300CV Specifications

General

Protection Class	IP20
Input Voltage	200-240V AC
Output Voltage	0-240 VDC
Storage Temperature	-20-60°C
Humidity	5-95% non-condensing
Operating Temperature	0-40°C
