6-11
Communication
Address
Parameter Name & Function Default Unit
Setting
Range
Control
Mode
RS232 RS485
Low voltage protection level
Cn051
Set the delay time of Cn052, which triggers low
voltage protection alarm, when voltage of drive
input power is lower than Cn051.
190 Volt
170
190
ALL 5F0H 0033H
Low voltage protection alarm delay time
Cn052
Set the delay time of Cn052, which triggers low
voltage protection alarm, when voltage of drive
input power is lower than Cn051.
0
x250
msec
0
100
ALL C8BH 0034H
Current offset automatic adjust (only used in
servo off)
Setting Explanation
Cn053
1
Drive executes current offset adjust and
then clears setting to 0 automatically
when the adjustment is finished.
0 x
0
1
ALL B91H 0035H
Drive warning setting
Cn054
Parameter Cn054 set by hex code, and each bit
represents for each alarm. Setting the
corresponding bit to 1 for the alarm is an warn
mode. Drive warns and then trigger alarm after
continuously executing the setting time of Cn055
when alarm occurs.
Ex: Set Cn054 to 0801H, and then set Cn055 to
100 when low voltage or overspeed alarm is a
warn, which triggers alarm one second later.
0000100000000001 is the setting status,
presenting in binary.
0000 x
0000
FFFF
ALL C8DH 0036H
Drive warning delays the time of triggering
alarm
Cn055
Parameter Cn054 set by hex code, and each bit
represents for each alarm. Setting the
corresponding bit to 1 for the alarm is an warn
mode. Drive warns and then trigger alarm after
continuously executing the setting time of Cn055
when alarm occurs.
Ex: Set Cn054 to 0801H, and then set Cn055 to
100 when low voltage or overspeed alarm is a
warn, which triggers alarm one second later.
0000100000000001 is the setting status,
presenting in binary.
0
x10
msec
0
300
ALL C8EH 0037H
