6-6
Communication
Address
Parameter Name & Function Default Unit
Setting
Range
Control
Mode
RS232 RS485
Automatic gain 1& 2 switch
Setting Explanation
0
Switch from gain 1 to 2 if torque command
is greater than Cn021.
1
Switch from gain 1 to 2 if speed command
is greater than Cn022.
2
Switch from gain 1 to 2 if acceleration
command is greater than Cn023.
3
Switch from gain 1 to 2 if position error
value is greater than Cn024.
Cn015.1
4
Switch from gain 1 to 2 by input contact
G-SEL. Set one of the multi function
terminals to option 15.
4 X
0
│
4
Pi
Pe
S
Automatic gain proportion switch
Setting Explanation
0 JSDAP new automatic gain proportion
Cn015.3
1 JSDAP old automatic gain proportion
0 X
1
│
0
ALL
C07H 000FH
PI/P control mode switch by Torque Command
Cn016
Set the Cn015.0=0 first.
If Torque Command is less than Cn016 PI control is
selected.
If Torque Command is greater than Cn016 P control
is selected.
200 %
0
│
399
Pi
Pe
S
C4BH 0010H
PI/P control mode switch by Speed Command
Cn017
Set the Cn015.0=1 first.
If Speed Command is less than Cn017 PI control is
selected.
If Speed Command is greater than Cn017 P control
is selected.
0 rpm
0
│
4500
Pi
Pe
S
C4CH 0011H
PI/P control mode switch by accelerate
Command
Cn018
Set the Cn015.0=2 first.
If Acceleration is less than Cn018 PI control is
selected.
If Acceleration is greater than Cn018 P control is
selected.
0 rps/s
0
│
18750
Pi
Pe
S
C4DH 0012H
PI/P control mode switch by position error
number
Cn019
Set the Cn015.0=3 first.
If Position error value is less than Cn019 PI control
is selected.
If Position error value is greater than Cn019 P
control is selected.
0 pulse
0
│
50000
Pi
Pe
S
C4EH 0013H
Automatic gain 1& 2 switch delay time.
Cn020
Speed loop 2 to speed loop 1, Change over delay,
when two control speed loops ( P&I gains 1 & 2) are
used.
0
x02
msec
0
│
10000
Pi
Pe
S
53CH 0014H
Automatic gain 1& 2 switch condition (Torque
command)
Cn021
Set Cn015.1=0 first.
When torque command is less than Cn021 , Gain 1
is selected.
When torque command is greater than Cn021, Gain
2 is selected
When Gain 2 is active and torque command
becomes less than Cn021 setting value, system will
automatically switch back to Gain 1 switch time
delay can be set by Cn020.
200 %
0
│
399
Pi
Pe
S
53DH 0015H
