9-3
※ Dimension for JSDEP-10A/15A/20A/30A
Model H H1 W
JSDEP-10A/15A 160 152 67
JSDEP-20A /30A 160 152 80
Unit: mm
※ Dimension for JSDEP-50A3 / 75A3
Model H H1 W
JSDEP-50A3/ 75A3 206 195 80
Unit: mm
