TECO JSMA-PMC15AB - Page 64

64
Communication
Address
Parameter
Name & Function Default Unit
Setting
Range
Control
Mode
RS232 RS485
DI-1 Active Level
Seting Explanation
0 Low Active (short with IG24)
★
Hn601.2
1 High Active
0 X
0
│
1
ALL C23H 0501H
DI-2
★
Hn602
Plearse refer to Hn601
--- X
001
│
11F
ALL C24H 0502H
DI-3
★
Hn603
Plearse refer to Hn601
--- X
001
│
11F
ALL C25H 0503H
DI-4
★
Hn604
Plearse refer to Hn601
--- X
001
│
11F
ALL C26H 0504H
DI-5
★
Hn605
Plearse refer to Hn601
--- X
001
│
11F
ALL C27H 0505H
DI-6
★
Hn606
Plearse refer to Hn601
--- X
001
│
11F
ALL C28H 0506H
Hn607
Reserve --- --- --- --- --- ---
Hn608
Reserve --- --- --- --- --- ---
Hn609
Reserve --- --- --- --- --- ---
Hn610
Reserve --- --- --- --- --- ---
Hn611
Reserve --- --- --- --- --- ---
Hn612
Reserve --- --- --- --- --- ---
★
New setting will become effective after re-cycling the power.
Warning! If any of programmable Inputs of DI-1 ~ DI-13 are set for the same type of function
then the logic state selection ( NO or NC selection) for these inputs must be the same type.
Otherwise an Alarm will be displayed. AL-07 (Abnormal DI/DO programming).
