ChallengerPlus Installation and Quick Programming Manual 9
Installing the control panel
See Figure 4 below for overall details of a TS-CHPLUS ChallengerPlus panel
installed in a TS0307 Universal Enclosure.
Figure 4: Challenger panel board mounted in enclosure (models TS-CHPLUS)
Figure 4 legend
Enclosure mounting points
Location of tamper switch
Installation guidelines
Challenger panels are designed, assembled and tested to meet the requirements
related to safety, emission and immunity with respect to environmental electrical
and electromagnetic interference, as of current relevant standards.
In addition to the general installation guidelines, installers must adhere to any
country dependent requirements of local applicable standards. Only a qualified
electrician or other suitably trained and qualified person should wire to and
provide General Purpose Outlets (GPO) or attempt to wire to the Public Switched
Telephone Network (PSTN).
