- Non-skid footwear is recommended when working outdoors.
- Wear protective hair covering to contain long hair.
9. Use protective equipment
- Use safety glasses and gloves.
- Use face or dust mask if working operations create dust.
10. Connect dust extraction equipment
- If the tool is provided for the connection of dust extraction and collecting equip
-
ment, ensure these are connected and properly used.
11. Do not abuse the cord
- Never yank the cord to disconnect it from the socket. Keep the cord away from
heat, oil and sharp edges.
12. Secure work
- Where possible use clamps or a vice to hold the work. It is safer than using your
hand.
13. Do not overreach
- Keep proper footing and balance at all times.
14. Maintain tools with care
- Keep cutting tools sharp and clean for better and safer performance.
- Follow instruction for lubricating and changing accessories.
- Inspect tool cords periodically and if damaged have them repaired by an author
-
ized service facility.
- Inspect extension cords periodically and replace if damaged.
- Keep handles dry, clean and free from oil and grease.
15. Disconnect tools
- When not in use, before servicing and when changing accessories such as
blades, bits and cutters, disconnect tools from the power supply.
16. Remove adjusting keys and wrenches
- Form the habit of checking to see that keys and adjusting wrenches are removed
from the tool before turning it on.
17. Avoid unintentional starting
- Ensure switch is in “off” position when plugging in.
18. Use outdoor extension leads
- When the tool is used outdoors, use only extension cords intended for outdoor
use and so marked.
19. Stay alert
- Watch what you are doing, use common sense and do not operate the tool when
you are tired.
20. Check damaged parts
- Before further use of tool, it should be carefully checked to determine that it will
operate properly and perform its intended function.
- Check for alignment of moving parts, binding of moving parts, breakage of parts,
mounting and any other conditions that may affect its operation.
- A guard or other part that is damaged should be properly repaired or replaced
by an authorized service centre unless otherwise indicated in this instruction
manual.
- Have defective switches replaced by an authorized service centre.
- Do not use the tool if the switch does not turn it on and off.
21. Warning
- The use of any accessory or attachment other than one recommended in this
instruction manual may present a risk of personal injury.
22.Haveyourtoolrepairedbyaqualiedperson
- This electric tool complies with the relevant safety rules. Repairs should only be
carriedoutbyqualiedpersonsusingoriginalspareparts,otherwisethismay
result in considerable danger to the user.
23. Warning
- Never stop the grinding wheel with your hands, even after the motor has been
switched off.
2. GENERAL INFORMATION
The manufacturer is not liable for damages in the following cases:
- failed observance of the instructions given herein;
- use of the appliance other than that described in the “INTENDED USE” section;
- failed use in compliance with current standards on Health & Safety at the workplace;
- Incorrect installation;
- lack of scheduled maintenance;
- modicationsorjobsthatarenotauthorizedbythemanufacturer;
- use of non-original or inadequate spare parts;
- repairs that are not carried out by a specialist.
3. WARRANTY
The warranty validity is that acknowledged in the country of sale. Claims under
warranty will only be accepted if they are backed-up by the copy of the purchase
document (bill or receipt) and product packaging (if possible intact).
The guarantee becomes void if:
a) the appliance has been tampered with;
b) the appliance has not been used according to this manual;
c)non-originalparts,appliancesorgrindingwheelshavebeenttedonthegrinder
or other parts that are not authorized by the manufacturer;
d) the appliance has been powered at a voltage or frequency different from that written
in the rating nameplate.
The warranty does not cover:
any mechanisms or parts affected by wear (such as the abrasive disk/grinding wheel,
the motor carbon brushes, vice, electrical switches and adjustment devices/knobs).
INDEX
1. SAFE OPERATION.................................................................................6
2. GENERAL INFORMATION ..................................................................... 6
3. WARRANTY ...........................................................................................6
4. USING AND KEEPING UP THE OWNER’S MANUAL ...........................7
5. DEFINITIONS .........................................................................................7
6. SYMBOLS ..............................................................................................7
7. TECHNICAL DATA ..................................................................................7
8. PART DESCRIPTION (FIG.1) .................................................................7
9. SAFETY DEVICES .................................................................................7
10. INTENDED USE .....................................................................................7
11. UNPACKING ...........................................................................................7
12. STANDARD SUPPLY (FIG.2) .................................................................7
13. TESTING THE GRINDING WHEEL .......................................................7
14. INSTALLATION ....................................................................................... 7
15. CHAIN INFORMATION ...........................................................................8
16. CHAIN IDENTIFICATION .......................................................................8
17. GRINDING WHEEL WARNINGS ............................................................8
18. FITTING THE GRINDING WHEEL .........................................................8
19. CHECKING THE ASSEMBLY OF THE GRINDING WHEEL ..................8
20. ELECTRICAL CONNECTION ................................................................8
21. START-UP ..............................................................................................8
22. CHECKING THE GRINDING WHEEL SHAPE ....................................... 8
23. GRINDING WHEEL DRESSING ............................................................8
24. ADJUSTING THE GRINDER ..................................................................8
25. SHARPENING WARNINGS ..................................................................9
26. SHARPENING THE CHAIN ....................................................................9
28. GRINDING WHEEL DRESSING FOR SHARPENING
THE DEPTH GAUGE .............................................................................9
29. SHARPENING THE DEPTH GAUGE .....................................................9
30. STOPPING AND SHUTTING DOWN .....................................................9
31. TROUBLE SHOOTING .........................................................................10
1. SAFE OPERATION
WARNING! When using electric tools basic safety precautions should always
befollowedtoreducetheriskofre,electricshockandpersonalinjuryincluding
the following. Read all these instructions before attempting to operate this
product and save these instructions”.
Remove the plug before carrying out any adjustment, servicing or maintenance.
1. Keep work area clear
- Cluttered areas and benches invite injuries.
2. Consider work area environment
- Do not expose tools to rain.
- Do not use tools in damp or wet locations.
- Keep work area well lit.
- Donotusetoolsinthepresenceofammableliquidsorgases.
3. Guard against electric shock
- Avoid body contact with earthed or grounded surfaces (e.g. pipes, radiators,
ranges, refrigerators).
4. Keep other persons away
- Do not let persons, especially children, not involved in the work touch the tool
or the extension cord and keep them away from the work area.
5. Store idle tools
- When not in use, tools should be stored in a dry locked-up place, out of reach
of children.
6. Do not force the tool
- It will do the job better and safer at the rate for which it was intended.
7. Use the right tool
- Do not force small tools to do the job of a heavy duty tool.
- Do not use tools for purposes not intended; for example do not use circular saws
to cut tree limbs or logs.
8. Dress properly
- Do not wear loose clothing or jewellery, they can be caught in moving parts.
