TECshow BEAMER 7R - 15 Channels DMX Functions

DMX Protocol
15 CHANNELS
Channel Function Eect
1 Pan scan 000-255 0°-540°
2 Tilt scan 000-255 0°-265°
3 Pan scan 16 Bit 000-255
4 Tilt scan 16 Bit 000-255
5 Pan/Tilt speed 000-255 from slow to fast
6 Dimmer 000-255 from dark to bright
7 Shutter
1-50 lamp on 51-240 strobe from slow to fast 241-255
lamp o
8 Frost 000-255 from strong to impotent
9 color 000-255 from color to color
10 Gobo 000-255 from gobo to gobo
11 Prism 0-127 non- change 128-255 8 facet prism
12 Prism rotate
0-106 clockwise rotate from slow to fast 107-180 anti-
clockwise from slow to fast 181-255 prism rotate and
shake from slow to fast
13 Focus 000-255
14 Lamp control
0-99 non- change 100-105 lamp o (keep on 3 seconds)
106-199 non- change 200-205 lamp on
(keep on 3 seconds)206-255 non- change
15 Reset 0-254 non- change 255 (keep on 3 seconds then reset)
p. 9BEAMER 7R
ENGLISH VERSION
