TECshow BEAMER - DMX Channel Configuration (11 Channel Modes); 11-Channel DMX Functions

11 Channel Modes
Channel Function Specication
CH1 X 0-255 0°-630°
CH2 Y 0-255 0°-235°
CH3 Dimmer 0-255 from dark to bright
CH4 Strobe
1-50 lamp on ;51-240 strobe from slow to fast; 241-255
lamp on
0-4 white; 5-9 gobo 1; 10-14 gobo 2; 15-19 gobo 3; 20-24
gobo 4; 25-29 gobo 5,30-34 gobo 6;35-39 gobo 7; 40-44
gobo 8; 45-49 gobo 9; 50-54 gobo 10; 55-59 gobo 11; 60-64
gobo 12; 65-69 gobo 13; 70-74 gobo 14, 75-84 gobo 14
shake; 85-94 gobo 13 shake; 95-104 gobo 12 shake; 105-
114 gobo 11 shake; 115-124 gobo 10 shake; 125-134 gobo
9 shake; 135-144 gobo 8 shake; 145-154 gobo 7 shake;
155-164 gobo 6 shake; 165-174 gobo 5 shake; 175-184 gobo
4 shake; 185-194 gobo 3 shake; 195-204 gobo 2 shake; 205-
214 gobo 1 shake; 215-255 gobo ow from slow to fast.
CH5 Gobo
CH6 Color
0-9 white, 10-19 red, 20-29 yellow, 30-39blue, 40-49 green
50-59 orange, 60-69 Magenta, 70-79pink, 80-89light blue,
90-99light yellow, 100-109dark blue,110-119olivine, 120-
129 CTB, 130-139 CTO,140-255 color rainbow eect
CH7 Prism 0-127 N/A 128-255 8-facet prism
CH8 Prism self-rotating
0-106 clockwise rotating from slow to fast,107-255 an-
ti-clockwise from slow to fast
CH9 Focus 0-255
CH10 Lamp on/o
0-99 N/A 100-105 Lamp o (interval 3 seconds) 106-199 N/A
200-205 Lamp on (interval 3 seconds) 206-255 N/A
CH11 Reset 0-254 N/A 255 (interval 3 seconds) Reset
BEAMER
ENGLISH VERSION
p. 8
