TECshow BEAMER - DMX Channel Configuration (14 Channel Modes); 14-Channel DMX Functions

DMX Channel
14 Channel Modes
Channel Function Specication
CH1 X 0-255 0 °-630 °
CH2 Y 0-255 0 ° -235 °
CH3 X16bit 0-255
CH4 Y16bit 0-255
CH5 X,Y speed 0-255 from fast to slow
CH6 Dimmer 0-255 from dark to bright
CH7 Strobe 1-50 lamp on 51-240 strobe from slow to fast; 241-255 lamp on
CH8 Gobo 0-255
CH9 Color 0-255
CH10 Prism 0-127 stay the same; 128-255 8 facet prism
CH11 Prism rotate
0-106 clockwise rotate, from slow to fast; 107-180 anticlockwise
rotate, from slow to fast; 181-255 prism self-rotate and shake,
from slow to fast
CH12 Focus 0-255
CH13 Lamp control
0-99 stay the same; 100-105 lamp o (stop 3 seconds) 106-199
stay the same; 200-205 lamp on (stop 3 seconds) ; 206-255 stay
the same
CH14 Reset 0-254 stay the same 255 (stay 3 seconds reset)
BEAMER
ENGLISH VERSION
p. 7
