BD_BE_BF_BSP 777 d
16 Betriebsanleitung / Operating manual / Instructions de service / Instrucciones de uso
D
7. Technische Daten
Baureihen P3961 mit 9999 Digit, 7-Segment
P3962 mit 19999 Digit, 7/14-Segment, Zweite Anzeige
Anzeige
• Genauigkeit
• Wandlungsrate
11 mm hoch, Bargraphanzeige
0,5 % v.EW. ± 1 Digit
1)
5 /sec
Messbereiche
nach EN
0...2 bar bis 0...700 bar, weitere auf Anfrage
Druckart positiver Überdruck, negativer Überdruck
Überlastgrenze 2-fach, max .1000 bar
Messstoff-
berührende Teile
Messbereiche
50 bar Edelstahl; Keramik; NBR ,
Messzelle Keramik
Messbereiche 100 bar nur Edelstahl,
Messzelle Dünnfilmtechnik
Druckanschluss G ¼ B, ¼ NPT, weitere Anschlüsse auf Anfrage
Stabilität pro Jahr
± 0,2 % v.EW. bei Referenzbedingungen
Speicher MIN / MAX (nicht flüchtig auch bei Batteriewechsel)
Programmb.
Parameter
• Passwort
• Tara
• autom.
Abschaltzeit
• Maßeinheit
P3961: ohne, P3962: einstellbar
P3961: ohne, P3962: 20% v.EW. einstellbar
P3961: ohne
P3962: einstellbar 0/15/30/60/120 min.
bar, PSI MPa wählbar
Beleuchtung
Display
P3961: ohne
P3962: mit
Spannungs-
versorgung
• Betriebsdauer
2 x 1,5V Mignonzelle AA
4000h (AA 2000 mAh)
1)
Messabweichung nach IEC 61298-2, einschließlich Nichtlinearität, Hysterese,
Nullpunkt- u. Endwertabweichung
