30 Betriebsanleitung / Operating manual / Instructions de service / Instrucciones de uso
GB
7. Technical Data
Models P3961 with 9999 digit, 7 segment
P3962 with 19999 digit, 7/14 segment, second display
Display
• Accuracy
• Conversion rate
11 mm high, bar graph display
0,5 % o.F.S. ± 1 digit
1)
5 /sec
Measuring ranges
to EN
0...2 bar to 0...700 bar, others on request
Type of pressure Positive overpressure, negative overpressure
Overload limit Twofold, max .1000 bar
Parts in contact
with material
measured
Measuring ranges
50 bar stainless steel; ceramic; NBR,
Measuring cell ceramic
Measuring ranges 100 bar only stainless steel,
measuring cell thin-film technology
Pressure connector G ¼ B, ¼ NPT, other connectors on request
Stability per year
± 0,2 % o.F.S. under reference conditions
Memory MIN/MAX (not volatile even when changing batteries)
Programming
mode Parameters
• Password
• Tare
• Automatic
switch off time
• Measuring unit
P3961: without, P3962: settable
P3961: without, P3962: 20% o.F.S. settable
P3961: without
P3962: 0/15/30/60/120 min.
bar, PSI MPa selectable
Illumination of
display
P3961: without
P3962: with
Voltage supply
• Operating life
2 x 1.5V Mignon cell AA
4000h (AA 2000 mAh)
1)
Measuring deviation to IEC 61298-2, including non-linearity, hysteresis,
deviation of zero point and upper range value
