TECSYSTEM NT538 ETH - 9 Ethernet Module Parameter Programming; Eth0 Connections; Telnet Enabling

26
NT538 ETH
X Windows Vista, 7, 8.
ETHERNET MODULE PROGRAMMING PARAMETER
ETH0 CONNECTIONS
Using an Ethernet cable, connect the RJ45 ETH0 of the NT538 ETH control unit to the ethernet card of a PC.
TELNET ENABLING
Use the Telnet program to set the Ethernet IP parameters.
1) START menu (Windows) If already enabled, the program appears
2) Start the search with the Telnet program Press ENTER to launch the program.
Entering telnet in SEARCH.
If the Telnet program is not enabled:
3) START menu (Windows):
6) Select Turn Windows features on or off
(Go to step 12 on page 27)
5) Select Programs, followed by Features or
Programs and Features
4) Select Control panel
