NT538 ETH

The following objects are present inside the box:

Control unit

Start guide and QR code

2 blocks for panel mounting

1 supply terminal 3 poles pitch 5

Code: 2PL0367- Screws tightening torque 0.5Nm

1 relay terminal 12 poles pitch 5

Code: 2PL0361- Screws tightening torque 0.5Nm

2 Pt100 sensor terminal 12 poles pitch 3.81

Code: 2PL0430 - Screws tightening torque 0.25Nm

ACCESSORIES

ATTENTION: always install the device using the terminals included in the pack.

The use of terminals other than those included with the control unit might cause malfunctions.
