TECSYSTEM NT538 ETH - 14 ) Troubleshooting; 15 ) Equipment Disposal; 16 Useful Contacts

33
NT538 ETH
FCD FUNCTION
TECHNICAL INFORMATION: ufficiotecnico@tecsystem.it
SALES INFORMATION: info@tecsystem.it
USEFUL CONTACTS
UL SPECIFICATION AND RATINGS
CABLE SPECIFICATION
Dimension for main circuit 18AWG, working temperature over 105°C
MASS OF THE EQUIPMENT
0,45 Kg
INPUT SUPPLY
100– 240 Vac / Vdc (±10%), 50/60 Hz, 7,5VA max
PROTECTION
External switch or circuit breaker
OUTPUTS RELAYS
5 relay Output: 10A 250Vac-res COS=1
PORT
Ethernet
Suitable for use on a flat surface of a type 1 enclosure if back panel is provided with two short fixing screws tightening
torque: 0.57Nm
