TECSYSTEM T154 Series User Manual

7
T154 SERIES
1)
3-digit display
11)
Enter/Reset button
2)
Control unit series
12)
Relay ON test (yellow) LED
3)
TRIP warning (red) LED
13)
Programming/Confirmation button
4)
ALARM warning (yellow) LED
14)
PRG ON (yellow) LED
5)
FAN warning (yellow) LED
15)
LED/relay test button
6)
FAULT warning (red) LED
16)
CH1-CH2-CH3-CH4 selected
channel (green) LED
7)
Scanning mode selection button
17)
T-max mode selection (red) LED
8)
Fixing block
18)
Man mode selection (yellow) LED
9)
UP button
19)
Auto mode selection (green) LED
10)
DOWN button
20)
Scan mode selection (yellow) LED
FRONT PANEL
1MN0044 REV. 0
1
2
3
4
5
6
7
8
9
10
11
12
14
13
15
16
17
18
19
20
1MN0044 REV. 0
2
3
4
5
6
7
8
9
10
11
1
