O
utdoor unit
• If an awning is built over the outdoor unit to prevent direct sunlight or rain exposure, make sure that
heat radiation from the condenser is not restricted.
• Ensure that the clearance around the back of the unit is more than 30 cm and left side is more than
30 cm. The front of the unit should have more than 200 cm of clearance and the connection side
(right side) should have more than 60 cm of clearance. (See picture 2)
• Do not place animals and plants or other obstacles in the path of the air inlet or outlet.
•
Take the air conditioner weight into account and select a place where noise and vibration will not be
an issue.
• Select a place so that the warm air and noise from the air conditioner do not disturb neighbours.
• Note that the outdoor unit produces sound when in use, this could interfere with local legislation. It
is the responsibility of the user to check and to make sure the equipment is in full compliance with
local legislation.
• Be sure to level the unit.
GENERAL
• Ensure the support structure and anchoring method are adequate for the unit location.
• Consult and follow local legislation regarding mounting and installation of air conditioner equip-
ment.
• If the outdoor unit is installed on roof structures or external walls, this may result in excessive noise
and vibration and may also be classed as a non serviceable installation.
• Always place the airconditioner in an easy accessible position.
ITEMS PACKED WITH THE UNIT (for TSCS models)
Number Name of Accessories Quantity
1 Installation plate 1
2 Clip Anchor 8
3 Self-tapping screw ‘A’ ST 3.9x25 8
4 Seal 1
5 Drain joint 1
6 Connecting pipe assembly 1
7 Remote controller 1
8 Self-tapping screw ‘B’ ST 2.9x10 2
9 Remote controller holder 1
4
84
1
2
3
4
5
6
7
8
9
