8
TO SERVICE AIR CLEANER
1. Loosen cover screw (A).
6. Install a new paper filter (part no. 36046) (C).
7. Clean and install pre-filter (if so equipped).
8. Reinstall cover to air cleaner body.
Be sure hinge is assembled properly.
9. Swing cover up and tighten cover screw. (Do not
over tighten).
2. Swing cover down and remove from hinge (B).
3. Pull foam pre-filter out of air cleaner body (if
equipped with pre-filter).
4. Pull air filter out of air cleaner body.
5. Clean air cleaner cover and body.
PRE-FILTER
A
B
C
