EC2975 Parts List
Main Board (cont) Main Board (cont)
Position Description Part Number Position Description Part Number
Capacitors (cont) Diodes (cont)
C856 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
D721 DIODE 1N4148 10-1N4148-AB1
C911 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
D731 DIODE ZENER 12V 5% 0W5 10-79C12V-DB1
C912 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
D732 DIODE ZENER 12V 5% 0W5 10-79C12V-DB1
C913 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
D803 DIODE EG01C 10-0EG01C-EB1
C921 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
D804 DIODE EU1Z 10-00EU1Z-E01
C922
CAP ELCO 47UF 20% 16V 25-BCB470-M1X D805 DIODE EU1Z 10-00EU1Z-E01
C923 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
D806 DIODE EU1Z 10-00EU1Z-E01
C931 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D807 DIODE ZENER 16V 5% 0.5W 10-79C16V-DB1
C932 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
D830 DIODE RU4YX 10-0RU4YX-E01
C933 CAP ELCO 220UF 20% 16V 25-BCB221-M1X
D831 DIODE RU3AM 10-0RU3AM-E01
C934 CAP ELCO 100UF 20% 16V 25-BCB101-M1X D832 DIODE TFR104 10-TFR104-EB3
C935 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 D833 DIODE EU2YX 10-0EU2YX-E01
C942 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 D834 DIODE EU2YX 10-0EU2YX-E01
C943 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D839 DIODE ZENER 3V9 5% 0W5 10-79C3V9-DB1
C944 CAP ELCO 100UF 20% 16V 25-BCB101-M1X D840 DIODE ZENER 10V 10-79C10V-DB1
C945 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 D841 DIODE ZENER 2V4 5% 0W5 10-79C2V4-DB1
C952 CAP ELCO 10UF 20% 16V 25-BCB100-M1X D842 DIODE 1N4148 10-1N4148-AB1
C953 CAP CERCO SL TUBU 33PF 5% 50V 26-EBP330-JZ1 D843 DIODE 1N4004(RECTIFIER) 10-1N4004-EB1
C961 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 DB801 DIODE D3SB60 10-D3SB60-H71
C962 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
Filter, Inductor, Resonator, Transformer
C969 CAP ELCO 100UF 20% 16V 25-BCB101-M1X
C971 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 D804 BEAD FERRITE HF70 35-237250-00X
C981 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D830 BEAD FERRITE HF70 35-237250-00X
C991 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D831 BEAD FERRITE HF70 35-237250-00X
T141 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1 D832 BEAD FERRITE HF70 35-237250-00X
D833 BEAD FERRITE HF70 35-237250-00X
Connectors
D834 BEAD FERRITE HF70 35-237250-00X
P911
RCA JACK 3P YEL.WHT.RED/SW Qty2
47-322900-00G L051 COIL PL 22UH 5% 34-R220J2-0EX
P931
RCA JACK 3P YEL.WHT.RED/SW Qty2
47-322900-00G L053 COIL PL 2.2UH 5% 34-R229J2-0EX
P981 YC SOCKET DSW 14 47-271260-004
L081
COIL PL 22UH 5% 34-R220J2-0EX
L121 COIL CHOKE 1UH 10% 34-A109K2-1IX
Diodes
L201 COIL PL 100UH 5% 34-R101J2-0EX
D031A LED HFR105 14-255670-LRX
L211 COIL PL 100UH 5% 34-R101J2-0EX
D041 DIODE 1N4148 10-1N4148-AB1
L251 COIL PL 22UH 5% 34-R220J2-0EX
D042 DIODE 1N4148 10-1N4148-AB1 L252 COIL PL 10UH 5% 34-R100J2-0EX
D043 DIODE 1N4148 10-1N4148-AB1 L253 COIL PL 12UH 5% 34-R120J2-0EX
D044 DIODE 1N4148 10-1N4148-AB1
L255 COIL PL 5U6H 5% 34-R569J2-0EX
D061 DIODE ZENER 5V1 5% 0W5 10-79C5V1-DB1 L256 COIL PL 12UH 5% 34-R120J2-0EX
D101 DIODE ZENER 5V1 5% 0W5 10-79C5V1-DB1 L262 COIL PL 12UH 5% 34-R120J2-0EX
D111 DIODE ZENER UPC 574J 10-PC574J-DJ1 L271 COIL PL 100UH 5% 34-R101J2-0EX
D211 DIODE 1N4148 10-1N4148-AB1 L412 COIL CHOKE 0U6H 10% 34-A608K6-1BX
D212 DIODE 1N4148 10-1N4148-AB1
L413 COIL LINEARITY 31UH 36-LIN310-XX1
D213 DIODE 1N4148 10-1N4148-AB1 L414 COIL CHOKE 15MH 36-WID153-XX1
D215 DIODE 1N4148 10-1N4148-AB1 L801 BEAD FERRITE HF70 35-237250-00X
D221 DIODE 1N4148 10-1N4148-AB1 L838 COIL CHOKE 22UH 10% 34-R220K2-1B3
D222 DIODE ZENER 4V7 5% 0W5 10-79C4V7-DB1 T271 COIL IFT 236560 VCO 38-236560-00X
D223 DIODE 1N4148 10-1N4148-AB1
T401 TRANSFORMER HORIZ DRIVER 36-107483-002
D280 DIODE 1N4148 10-1N4148-AB1 T461 FLYBACK JF0702C 37-JF0702-C0X
D411 DIODE BY228 10-0BY228-E01 T801 LINE FILTER (LCL-2826) 36-304090-002
D412 DIODE TFR104 10-TFR104-EB3 T802 TRANSFORMER KB49C1090 36-235480-015
D421 DIODE TFR104 10-TFR104-EB3 T803 LINE FILTER 20MH 36-238300-002
D431 DIODE TFR104 10-TFR104-EB3
X051 CRYSTAL 8.0MHZ 45-252300-105
D441 DIODE TFR104 10-TFR104-EB3 X201 CRYSTAL 4.43 MHZ 45-107190-10X
D471 DIODE ZENER 8.2V 5% 0.25W 10-79C8V2-DB1 Z141 SAW FILTER K3350K 38.9MHZ 45-SAW38M-9Y2
D631 DIODE 1N4148 10-1N4148-AB1 Z251 CER TRAP TPS 6.5MHZ 45-130390-60X
D632 DIODE 1N4148 10-1N4148-AB1 Z253 CER TRAP TPS 5.5MHZ 45-135070-60X
D711 DIODE 1N4148 10-1N4148-AB1
Z254 CER TRAP 6.0MHZ 45-137170-60X
Z261 CER FILTER 5.5MHZ 45-107742-40X
Z262 CER FILTER 6.5MHZ 45-107741-40X
Z263 CER FILTER 6.0MHZ 45-108780-40X
45. 5 of 8
