EC2975 Parts List
Main Board (cont) Main Board (cont)
Position Description Part Number Position Description Part Number
Integrated Circuit
Resistors (cont)
IC001 IC TMP87CS38N M3 TSB 13-274020-00P R073 RES CF 100R 5% 0W166 18-CB0101-JNX
IC002 IC M24C08 13-M24C08-00P R074 RES CF 3K3 5% 0W166 18-CB0332-JNX
IC201 IC TB1240AN 13-TB1240-ANP R075 RES CF 100R 5% 0W166 18-CB0101-JNX
IC261 IC 4052 13-000040-52P R076 RES CF 3K3 5% 0W166 18-CB0332-JNX
IC301 IC TA8427K 13-00TA84-27P R077 RES CF 47R 5% 0W166 18-CB0470-JNX
IC601 IC TDA2616 13-0TDA26-16S R084 RES CF 47R 5% 0W166 18-CB0470-JNX
IC651 IC TA1216AN 13-TA1216-ANP R085 RES CF 47R 5% 0W166 18-CB0470-JNX
IC801 IC STR-F6656 13-STRF66-56P R091 RES CF 1K 5% 0W166 18-CB0102-JNX
IC802 PHOTO COUPLER SFH615A3C 15-SFH615-A3C R092 RES CF 22K 5% 0W166 18-CB0223-JNX
IC831 IC SE140N 13-00SE14-0NS R101 RES CF 10K 5% 0W166 18-CB0103-JNX
IC841 IC L7805C-VAP 13-L7805C-VAP R102 RES CF 10K 5% 0W166 18-CB0103-JNX
IC851 IC MC7809C (LINEAR +9V 1A) 13-00MC78-09S R103 RES CF 47R 5% 0W5 18-CE0470-JNX
IC961 IC 4052 13-000040-52P R111 RES CF 3K3 5% 0W166 18-CB0332-JNX
IC962 IC 4052 13-000040-52P R112 RES CF 15K 5% 0W166 18-CB0153-JNX
R113 RES CF 15K 5% 0W166 18-CB0153-JNX
Resistors
R114 RES CF 33K 5% 0W166 18-CB0333-JNX
J782 RES MO 4K7 5% 0W5 18-FE0472-JMX R115 RES CF 47K 5% 0W166 18-CB0473-JNX
R003 RES CF 100R 5% 0W166 18-CB0101-JNX R116 RES CF 10M 5% 0W166 18-CB0106-JNX
R005 RES CF 10K 5% 0W166 18-CB0103-JNX R122 RES CF 56R 5% 0W166 18-CB0560-JNX
R006 RES CF 100R 5% 0W166 18-CB0101-JNX R123 RES CF 180R 5% 0W166 18-CB0181-JNX
R007 RES CF 100R 5% 0W166 18-CB0101-JNX
R124 RES CF 1K 5% 0W166 18-CB0102-JNX
R009 RES CF 100R 5% 0W166 18-CB0101-JNX R125 RES CF 470R 5% 0W166 18-CB0471-JNX
R012 RES CF 220R 5% 0W166 18-CB0221-JNX R127 RES CF 150R 5% 0W166 18-CB0151-JNX
R013 RES CF 3K3 5% 0W166 18-CB0332-JNX R200 RES CF 1K 5% 0W166 18-CB0102-JNX
R014 RES CF 3K3 5% 0W166 18-CB0332-JNX R201 RES CF 4K7 5% 0W166 18-CB0472-JNX
R015 RES CF 100R 5% 0W166 18-CB0101-JNX
R202 RES CF 2K2 5% 0W166 18-CB0222-JNX
R016 RES CF 100R 5% 0W166 18-CB0101-JNX R203 RES CF 220R 5% 0W166 18-CB0221-JNX
R017 RES CF 10K 5% 0W166 18-CB0103-JNX R204 RES CF 1K5 5% 0W166 18-CB0152-JNX
R021 RES CF 47R 5% 0W166 18-CB0470-JNX R205 RES CF 100K 5% 0W166 18-CB0104-JNX
R022 RES CF 8K2 5% 0W166 18-CB0822-JNX R206 RES CF 100K 5% 0W166 18-CB0104-JNX
R029 RES CF 10K 5% 0W166 18-CB0103-JNX
R208 RES CF 33K 5% 0W166 18-CB0333-JNX
R031 RES CF 10K 5% 0W166 18-CB0103-JNX R211 RES CF 4K7 5% 0W166 18-CB0472-JNX
R034 RES CF 3K3 5% 0W166 18-CB0332-JNX R212 RES CF 1K5 5% 0W166 18-CB0152-JNX
R035 RES CF 4K7 5% 0W166 18-CB0472-JNX R213 RES CF 1K5 5% 0W166 18-CB0152-JNX
R036 RES CF 2K2 5% 0W166 18-CB0222-JNX R214 RES CF 1K5 5% 0W166 18-CB0152-JNX
R037 RES CF 470R 5% 0W166 18-CB0471-JNX
R215 RES CF 220R 5% 0W166 18-CB0221-JNX
R041 RES CF 2K2 5% 0W166 18-CB0222-JNX R216 RES CF 220R 5% 0W166 18-CB0221-JNX
R042 RES CF 2K2 5% 0W166 18-CB0222-JNX R217 RES CF 220R 5% 0W166 18-CB0221-JNX
R043 RES CF 2K2 5% 0W166 18-CB0222-JNX
R218 RES CF 2K2 5% 0W166 18-CB0222-JNX
R044 RES CF 2K2 5% 0W166 18-CB0222-JNX
R220 RES CF 1K 5% 0W166 18-CB0102-JNX
R051 RES CF 10K 5% 0W166 18-CB0103-JNX
R221 RES CF 7K5 5% 0W166 18-CB0752-JNX
R052 RES CF 47K 5% 0W166 18-CB0473-JNX
R222 RES CF 330R 5% 0W166 18-CB0331-JNX
R053 RES CF 100K 5% 0W166 18-CB0104-JNX R223 RES CF 330R 5% 0W166 18-CB0331-JNX
R054 RES CF 10K 5% 0W166 18-CB0103-JNX R225 RES CF 10K 5% 0W166 18-CB0103-JNX
R055 RES CF 10K 5% 0W166 18-CB0103-JNX R226 RES CF 180R +/-5% OW25 18-CD0181-JMX
R056
RES CF 100K 5% 0W166 18-CB0104-JNX
R227 RES CF 2K7 5% 0W166 18-CB0272-JNX
R057 RES CF 15K 5% 0W166 18-CB0153-JNX
R228 RES CF 560R 5% 0W166 18-CB0561-JNX
R061 RES CF 10K 5% 0W166 18-CB0103-JNX R229 RES CF 330R 5% 0W166 18-CB0331-JNX
R062 RES CF 1K 5% 0W166 18-CB0102-JNX
R231 RES.CF 6.2K OHM 18-CB0622-JNX
R063 RES CF 1K5 5% 0W166 18-CB0152-JNX R232 RES CF 8K2 5% 0W166 18-CB0822-JNX
R064 RES CF 10R 5% 0W25 18-CD0100-JMX
R241 RES CF 100R 5% 0W166 18-CB0101-JNX
R065 RES CF 100R 5% 0W166 18-CB0101-JNX R243 RES CF 1K 5% 0W166 18-CB0102-JNX
R066 RES CF 4K7 5% 0W166 18-CB0472-JNX R244 RES CF 12K 5% 0W166 18-CB0123-JNX
R067 RES CF 1K 5% 0W166 18-CB0102-JNX R251 RES CF 220K 5% 0W166 18-CB0224-JNX
R071 RES CF 1K 5% 0W166 18-CB0102-JNX R252 RES CF 470R 5% 0W166 18-CB0471-JNX
R072 RES CF 15K 5% 0W166 18-CB0153-JNX
R253 RES CF 100R 5% 0W166 18-CB0101-JNX
R254 RES CF 3K3 5% 0W166 18-CB0332-JNX
R255 RES CF 220R 5% 0W166 18-CB0221-JNX
R256 RES CF 330R 5% 0W166 18-CB0331-JNX
R258 RES CF 220R 5% 0W166 18-CB0221-JNX
