EC2906 Parts List
Boards and Assemblies
CRT Base Board (cont.)
Position Description Part Number Position Description Part Number
ASSY IR HANDSET "E" 08-2906XT-RMN
Transistors
CRT Base Board EC2906-L
Main Board EC2906-O
Q501 TRANS 2SC4544 11-SC4544-0A3
Q502 TRANSISTOR 2PC1815Y 11-PC1815-YBX
Cabinet Front Q503 TRANS 2SC4544 11-SC4544-0A3
Q504 TRANSISTOR 2PC1815Y 11-PC1815-YBX
ASSY CRT GND WIRE 02-271380-003 Q505 TRANS 2SC4544 11-SC4544-0A3
CRT 29" A68CNFD022Y2201
FORTUNE
NC012+AA925
CRT FIBRE SHEET qty 4 54-314740-0X0 Q506 TRANSISTOR 2PC1815Y 11-PC1815-YBX
DEGAUSSING COIL 36-294960-017 Q507 TRANSISTOR 2SA562TM-0 11-A562TM-0B3
FRONT CABINET 55-2906FC-0CNAB
Resistors
HOLDER POWER CORD 62-216340-0UA
LENS 56-2906LE-0HCAA R501 RES CF 560R 5% 0W166 18-CB0561-JNX
LOGO 67-366140-1A0AC R502 RES CF 680R 5% 0W166 18-CB0681-JNX
PAD RUBBER 25MM 7MM qty 6 59-130460-00X R503 RES CF 680R 5% 0W166 18-CB0681-JNX
POWER BUTTON 56-2906PK-0HAAB R505 RES CF 560R 5% 0W166 18-CB0561-JNX
R506 RES CF 680R 5% 0W166 18-CB0681-JNX
POWER CORD 3R/P W/HOUSING 51-KC0245-0CH
POWER SW ADAPTER 62-269940-0HA R508 RES CF 680R 5% 0W166 18-CB0681-JNX
PUSH BUTTON 56-2906FB-0HAAB R509 RES CF 680R 5% 0W166 18-CB0681-JNX
S/T SCREW AB Blk 4mm 15mm qty 4 63-B40150-AB3 R510 RES CF 560R 5% 0W166 18-CB0561-JNX
S/T SCREW H 6MM 30MM AB qty 4 63-H60300-AB4 R511 RES CF 680R 5% 0W166 18-CB0681-JNX
R513 RES CF 680R 5% 0W166 18-CB0681-JNX
S/T SCREW W HS 3MM 14MM qty 8 63-W3014X-HS4
SCREW ST 3MM 10MMAB qty 4 63-W3010X-AB4 R514 RES CF 2K7 5% 0W166 18-CB0272-JNX
SPACER CRT MOUNTING 2MM qty 4 54-205140-000 R515 RES CF 1K 5% 0W166 18-CB0102-JNX
SPEAKER 8 OHM 8W qty 2 42-61308F-XX2 R516 RES MO 18K 5% 2W 18-FG0183-JHX
SPRING CRT 6MM 50MM 0.6MM 67-216790-0E0 R517 RES MO 18K 5% 2W 18-FG0183-JHX
R518 RES MO 18K 5% 2W 18-FG0183-JHX
SPRING KNOB 67-250450-0E0
SUPPORT POST qty 2 62-357060-0UN
R519 RES M O 2K7 +/-5% 0W5 18-FE0272-JNX
WASHER 6MM 18MM 2MM qty 4 65-A6018X-20E
R520 RES M O 2K7 +/-5% 0W5 18-FE0272-JNX
R521 RES M O 2K7 +/-5% 0W5 18-FE0272-JNX
Cabinet Rear
R522 RES CF 680R 5% 0W166 18-CB0681-JNX
INLAY REAR AV 58-2506RI-9UIAA
Main Board
PAD RUBBER 25MM 7MM qty 2 59-130460-00X
PLATE MODEL NO 58-2906MP-0UIAB Capacitors
REAR CABINET 55-2906RC-0ENAA
S/T SCREW B 4x20 AB qty 10 63-B40200-AB3
CAP CER 220PF +/-5% 2KV 26-AMK221-JZX
C001 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
S/T SCREW F 3x10 BT qty 3 63-F30100-BT3 C002 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C004 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
CRT Base Board
C013 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
Capacitors C021 CAP CERCO 220PF 5% 50V 26-EBP221-JC1
C032 CAP CERCO 100PF 5% 50V 26-EBP101-JC1
C501 CAP CERCO 390PF 5% 50V 26-EBP391-JC1 C041 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
C502 CAP CERCO 390PF 5% 50V 26-EBP391-JC1 C042 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
C503 CAP CERCO 470PF 5% 50V 26-EBP471-JC1 C043 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
C504 CAP ELEC 10UF +/-20% 250V 25-BLA100-M1X
C505 CAP CER 1000PF +/-10% 2KV 26-AMK102-KRX C044 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
C051 CAP CERCO 39PF 5% 50V 26-EBP390-JC1
C506 CAP ELCO 470UF 20% 16V 25-BCB471-M1X C052 CAP PE 0U01F 5% 50V 27-PBC103-J0X
C508 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C053 CAP CERCO CH 22PF 5% 50V 26-EBP220-JC1
C509 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C054 CAP CERCO CH 22PF 5% 50V 26-EBP220-JC1
Connectors C055 CAP CERCO SL 30PF 5% 50V 26-EBP300-JZ1
C056 CAP CERCO SL 30PF 5% 50V 26-EBP300-JZ1
S501 SOCKET CRT GZS10-2-4 S1 47-265540-0U7 C061 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C062 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
Diodes C063 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
D501 DIODE 1N4148 10-1N4148-ABX C064 CAP ELCO 100UF 20% 16V 25-BCB101-M1X
D502 DIODE 1N4148 10-1N4148-ABX C070 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
C071 CAP CERCO 100PF 5% 50V 26-EBP101-JC1
Filters, Inductors C072 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1
C073 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1
L501 DIODE 1N4148 10-1N4148-ABX
L502 COIL CHOKE 10UH 10% 34-R100K2-1B3 C074 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
L505 BEAD FERRITE HF70 qty 2 35-237250-00X C075 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
L506 BEAD FERRITE HF70 qty 2 35-237250-00X C082 CAP ELCO 470UF 20% 16V 25-BCB471-M1X
C083 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
C084 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
