EC2906 Parts List
Main Board (cont.) Main Board (cont.)
Position Description Part Number Position Description Part Number
Capacitors (cont.) Capacitors (cont.)
C085 CAP CERCO 330PF 5% 50V 26-EBP331-JC1 C307 CAP MPE 0.22UF +/-5% 50V 27-MBC224-J0X
C091 CAP CERCO 330PF 5% 50V 26-EBP331-JC1 C308 CAP PE 0U039F 5% 50V 27-PBC393-J01
C092 CAP CERCO 220PF 5% 50V 26-EBP221-JC1 C309 CAP ELCO 2200UF 20% 35V 25-BEG222-M1X
C101 CAP ELCO 4.7UF +/-20% 50V 25-BFB479-M1X C311 CAP ELCO 10UF +/-20% 50V 25-BFB100-M1X
C102 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X C312 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C106 CAP ELCO 10UF 20% 16V 25-BCB100-M1X C401 CAP CERCO B 0U01F 10% 500V 26-AIM103-KBX
C107 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 C402 CAP CERCO B 3N3F 10% 500V 26-AIC332-KBX
C111 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C403 CAP CERCO 390PF 10% 500V 26-AIC391-KBX
C112 CAP CERCO 220PF 5% 50V 26-EBP221-JC1 C411 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C113 CAP MPE 0.22UF +/-5% 50V 27-MBC224-J0X C413 CAP MPP 0.0033UF 5% 1K6V 27-ALQ332-J01
C114 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 C414 CAP M PP 5600PF +/-5% 1.6KV 27-ALQ562-J0X
C121 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C415 CAP MPP 0U0066F 5% 1.6KV 27-ALR662-J01
C124 CAP ELCO 4.7UF +/-20% 50V 25-BFB479-M1X C416 CAP PP 0U022F 5% 400V 27-RHQ223-J0X
C125 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C417 CAP ELEC 4.7UF +/-20% 50V 25-264610-M1X
C126 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C418 CAP M/PP 0U39F 5% 400V 27-AHR394-J01
C127 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 C421 CAP ELCO 10UF +/-20% 200V 25-BKA100-M1X
C128 CAP CERCO SL TUBU 33PF 5% 50V 26-EBP330-JZ1 C422 CAP ELCO 100UF +/-20% 200V 25-BKG101-M1X
C201 CAP PE 0.022UF +/-5% 50V 27-PBC223-J0X C431 CAP CERCO B 220PF 10% 500V 26-AIC221-KBX
C202 CAP ELCO 47UF 20% 16V 25-BCB470-M1X C432 CAP ELCO 1000UF 20% 35V 25-BEA102-M1X
C203 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C441 CAP CERCO B 220PF 10% 500V 26-AIC221-KBX
C204 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 C442 CAP ELEC 10UF +/-20% 250V 25-BLA100-M1X
C205 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C451 CAP PP 0.056UF +/-5% 400V 27-RHQ563-J0X
C206 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C452 CAP CERCO 2200PF 10% 50V 26-EBP222-KB1
C207 CAP PE 0.0022UF +/-5% 50V 27-PBC222-J0X
C471 CAP MPE 2700PF +/-5% 100V 27-MCB272-J0X
C208 CAP ELCO 0U47F 20% 50V 25-BFB478-M1X
C602 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C209 CAP CERCO CH 12PF 5% 50V 26-EBP120-JC1
C605 CAP ELCO 100UF +/-20% 50V 25-BFB101-M1X
C211 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X
C606 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C212 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X C607 CAP ELCO 470UF 35V +/-20% 25-BEA471-M1X
C213 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X C608 CAP ELCO 470UF 35V +/-20% 25-BEA471-M1X
C214 CAP ELCO 10UF 20% 16V 25-BCB100-M1X C609 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
C215 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C610 CAP ELCO 1000UF 20% 35V 25-BEA102-M1X
C217 CAP ELCO 100UF 20% 16V 25-BCB101-M1X C611 CAP PE 0.022UF +/-5% 50V 27-PBC223-J0X
C221 CAP PE 0.0022UF +/-5% 50V 27-PBC222-J0X C612 CAP PE 0.022UF +/-5% 50V 27-PBC223-J0X
C222 CAP ELCO 10UF +/-20% 50V 25-BFB100-M1X C631 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C223 CAP ELCO 1UF +/-10% 50V 25-GFB109-K1X C634 CAP ELCO 220UF 20% 16V 25-BCB221-M1X
C224 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 C635 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
C226 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C651 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C227 CAP ELCO 10UF 20% 16V 25-BCB100-M1X C652 CAP PE 0.0082UF +/-5% 50V 27-PBC822-J0X
C228 CAP ELCO 100UF 20% 16V 25-BCB101-M1X C653 CAP PE 0.027UF +/-5% 50V 27-PBC273-J0X
C228A CAP CERCO 220PF 5% 50V 26-EBP221-JC1 C654 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C229 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C655 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C242 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X C656 CAP PE 0.0082UF +/-5% 50V 27-PBC822-J0X
C244 CAP PE 0U0047F 5% 50V 27-PBC472-J01 C657 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
C252 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X C658 CAP ELCO 100UF 20% 16V 25-BCB101-M1X
C253 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C659 CAP PE 0.027UF +/-5% 50V 27-PBC273-J0X
C254 CAP CERCO 100PF 5% 50V 26-EBP101-JC1
C661 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C255 CAP CERCO 100PF 5% 50V 26-EBP101-JC1
C662 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C256 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
C663 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C257 CAP ELCO 100UF 20% 16V 25-BCB101-M1X C664 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C261 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1 C665 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C262 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1 C666 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C265 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 C671 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C271 CAP ELCO 0.1UF +/-20% 50V 25-BFB108-M1X C672 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C272 CAP CERCO 100PF 5% 50V 26-EBP101-JC1 C673 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
C273 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C674 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
C274 CAP ELCO 47UF 20% 16V 25-BCB470-M1X C675 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
C275 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C731 CAP ELCO 100UF 20% 35V 25-BEB101-M1X
C276 CAP ELCO 10UF 20% 16V 25-BCB100-M1X C732 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
C278 CAP ELCO 22UF 20% 16V 25-BCB220-M1X C745 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
C301 CAP CERCO 330PF 5% 50V 26-EBP331-JC1 C801 CAP MPP 0.22UF +/-20% 250VAC 27-AQT224-MVJ
C302 CAP PE 0.033UF +/-5% 50V 27-PBC333-J0X
C802 CAP MPP 0.22UF +/-20% 250VAC 27-AQT224-MVJ
C303 CAP ELCO 2200UF 20% 35V 25-BEG222-M1X
C802A CAP METAL PE 0.1UF 10% 400V 27-MHM104-K0X
C304 CAP PE 0.056UF +/-5% 50V 27-PBC563-J0X
C803 CAP CERCO 4700PF +80-20 250VAC 26-AQK472-ZFX
C305 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C804 CAP CERCO 4700PF +80-20 250VAC 26-AQK472-ZFX
C306 CAP ELCO 220UF +/-20% 35V 25-BEA221-M1X C805 CAP CERCO B 0U01F 10% 500V 26-AIM103-KBX
58. 3 of 7
