Notes
Pump cycles too 1. Pipes leak 1. Check connections
frequently 2. Faucets or valves are open 2. Close faucets or valves
3. Foot valve leaks 3. Replace foot valve
4. Pressure switch is out of adjustment 4. Adjust or replace pressure switch
5. Air charge too low in pre-charged tank 5. DISCONNECT ELECTRICAL POWER and open faucets
until all pressure is relieved. Using automobile tire
pressure gauge, check air pressure in tank at the
valve stem located at top of tank. Pressure should
be 2 psi less than cut-in pressure of pump pressure
switch. If necessary,add air pressure with an air
hose. Check air valve for leaks, using a soapy
solution, and replace core if necessary
Air spurts from 1. Pump is picking up prime 1. As soon as pump picks up prime, all air will be
faucets ejected
2. Leak in suction side of pump 2. Check suction piping
3. Well is gaseous 3. Change installation as described in manual, Page 14
4. Intermittent over-pumping of well 4. Lower foot valve if possible, otherwise restrict
discharge side of pump
Teel Operating Instructions and Parts Manual
Teel Standard Jet Pumps
and Systems
Manufactured for Dayton Electric Mfg. Co.
Niles, Illinois 60714 U.S.A.
3P683D, 3P684D, 2P899A and 3P715B
®
®
E
N
G
L
I
S
H
Symptom Possible Cause(s) Corrective Action
Troubleshooting Chart (Continued)
