Step Two
Attach the Upper Support
Arms to the Table Bed
(EP-1141)
• Before following this step, make
sure you have read the orange
insert that came attached to the
Table Bed.
• Place the Table Bed face down
on the fl oor and push down on
the Support Beam, so the two
holes align evenly with holes
at the base of Upper Support
Arms (Figure 3). You may have
to exert extra pressure to ensure
the Support Beam slides over the
rubber spacers.
• Insert the two bolts (EP-1149)
through the rubber spacers and
into the open holes.
• Fasten each bolt with a nut.
• Use the Allen Wrench to steady
(EP-1150) the bolts, tighten the
nut onto the bolt with the larger
wrench (F5-1088) (Figure 4).
Repeat with the second bolt.
5
ASSEMBLY
Figure 3
Figure 4
Teeter Hang Ups EP-950
Support Beam
Upper Support Arms
To Next Page
