ASSEMBLY
Step Five
Insert the Main Shaft (IA-1107) into
the Table Bed (EP-1140)
• Loosen the De-rattler knob on the Main
Shaft Housing.
• With the height adjustment settings on
the Main Shaft facing up, slide the end
of the Main Shaft into the Main Shaft
Housing on the Table Bed.
• Pull out the height-selector locking pin
to allow the Main Shaft to slide in
farther (Figure 10). For the purpose of
easy assembly, slide in the Main Shaft
and release the pin in the last height
setting (Refer to the Owner’s Manual
for proper height adjustment before
use).
NOTE: The De-rattler knob is an
optional accessory that helps prevent
a slight shift in the table when you
invert. The security of the product is
not compromised if you choose not to
tighten the knob.
• The Main Shaft must rest against the
Crossbar of the A-frame
(Figure 11). The Crossbar prevents
the table from rotating forward when
the user steps on the Foot Platform.
If the Main Shaft does not rest on the
Crossbar as shown in Figure 11 then
the Table Bed has been assembled
backwards onto the A-frame and this
must be corrected before use.
Figure 10
Teeter Hang Ups EP-950
De-rattler Knob
Main Shaft
Housing
Height-Selector
Locking Pin
Figure 11
Crossbar
