Image B
Go back to Step 7 for instruction.
Demonstrates that the Table Bed has been
assembled into the A-Frame backwards so the
Main Shaft is not resting on the Crossbar and must be corrected.
Image A
Go back to Step 6 for instruction.
Demonstrates that the Roller Hinges have been
assembled upside down into the Table Bed
and must be corrected.
Misassembly Check
If your Teeter Inversion Table looks like either of these images, your inversion table has
been misassembled and is unfit for use. Improper assembly could result in serious injury or death!
WARNING
!
15
