Teeter NXT-S - Items for Assembly

2
Items for Assembly
Items not shown to scale. Hardware drawings located on the insert inside each Hardware Kit.
ITEM NO. ITEM NAME
A-Frame Base Assembly
NX1105 A-Frame
F51007 Angle Tether
pre-assembled to A-Frame
Handle & Hinge Cover Assembly
NX1550 Support Handles (2)
HK1009 Handle Assembly Hardware Kit
F11250 Hinge Covers (2)
HK1002 Hinge Cover Assembly Hardware Kit
Ankle Comfort Dial Assembly
IA1119 Ankle Comfort Dial
HK1005 Ankle Comfort Dial Assembly Hardware Kit
Rear Ankle Bar Assembly
IA1113 Rear Ankle Bar
HK1003 Rear Ankle Bar Assembly Hardware Kit
Front Ankle Bar Assembly
EP1045 Front Ankle Bar
HK1004 Front Ankle Bar Assembly Hardware Kit
NX1750
NX1730
Product Support
F51088
ComforTrak Table Bed Assembly
use Table Bed Assembly
Hardware Kit (HK1006)
Main Shaft
with T-Pin Ankle Lock System
Roller Hinge Assembly
Optional Accessories
Tools Provided for Assembly
IA1149 F51130
E61301A
EP1045
F51064
E61105
E61300B
E61600
IA1113
Ankle Comfort Dial Assembly
use Ankle Comfort Dial Assembly
Hardware Kit (HK1005)
Rear Ankle Bar Assembly
use Rear Ankle Bar Assembly
Hardware Kit (HK1003)
Front Ankle Bar Assembly
use Front Ankle Bar Assembly
Hardware Kit (HK1004)
Support Handle Assembly
use Support Handle Assembly
Hardware Kit (HK1009)
NX1550
Base Assembly
with pre-assembled Angle Tether
NX1105
F51007
F11250
Hinge Cover Assembly
use Hinge Cover Assembly
Hardware Kit (HK1002)
IA1119 IA1118
ITEM NO. ITEM NAME
Table Bed Assembly
E61301A Upper Portion
E61300B Lower Portion
HK1006 Table Bed Assembly Hardware Kit
Roller Hinge Assembly
F51064 3-Hole Roller Hinges
Main Shaft
E61600 with T-Pin Ankle Lock System
Optional Accessories
E61105 Head Pillow
Tools Provided for Assembly
F51088 10/13mm Open-Ended Wrenches (2)
IA1149 5mm Allen Wrench (1)
F51130 Screwdriver (1)
Product Support
NX1730 Getting Started DVD
NX1750 Owner’s Manual
(attached to A-Frame)
