5.3. Precoating of the filter cartridges
For a longer service life of the filter cartridges they are pretreated with a filter aid in the factory.
If the fan unit and the filter unit of the filter device are only connected to one another
on site, then the filter cartridges have not yet been pretreated at the factory. Then the precoating
can only be carried out during the commissioning at the operation site.
When the operator orders and installs new filter cartridges, we recommend to also precoat them before
the commissioning.
Please read and refer to "Precoating new filter cartridges" in the chapter "Maintenance". There
you can also find a description of the operating method of the precoat.
5.4. Connecting the compressed air supply
The compressed air must be dry and oil-free.
According to ISO 8573-1:2010 the compressed air quality must at least meet: [7:4:4]
➔ Particle size: <40µm
➔ Pressure dew point: <= +3°C
➔ Oil content: <=5mg/m³
5.4.1. Compressed air supply for the cleaning of the filter cartridges
The filter cartridges of the system are automatically cleaned. Cleaning is carried out pneumatically via a
built-in compressed air tank.
Without compressed air supply the filter cartridges will become dirty very quickly.
● The external compressed air supply must be assured with an approved compressed air hose.
For the connection to the device, the compressed air hose must be equipped with a quick
coupling for an insert sleeve DN 7.2.
The compressed air must be dry and oil-free.
● The operating pressure of the compressed air supply must be a minimum of 3 bars and
maximum of 4 bars.
In case of the pressure being too low, the compressed air tank does not reach
quickly enough the operating pressure for the following cleaning. There is a risk of
material damage when the pressure is too high.
● Connect the compressed air hose to the insert sleeve (see chapter 2.1).
BA_FilterCube_4_IFA_20230808_EN
