15
HC-670
Modèle HC-670
Panneau Frontal de Commande
1 Panneau de Commande
2 Joint de Four
3 Résistance du Grill
4 Support Chromé
5 Grille
6 Plateau
(*)
7 Charnière
8 Porte
(*)
9 Sortie de l’air
de Réfrigération
10 Fixation au Meuble
11 Ecran du Grill
12 Sortie des Fumées
13 Lampe
14 Panneau du Fond
Catalytique
15 Turbine
16 Verre Intérieur Trempé
MODE
HC670
1 2 3 4
1 Horloge électronique.
2 Voyant lumineux de chauffage. Il indique
que la chaleur est transmise à l'aliment et
s'éteint quand la température choisie est
atteinte.
3 Sélecteur de fonctions.
4 Sélecteur de températures.
HC670
MODE
1
2
3
5
6
7
8
4
10
9
11
13
12
14
15
16
(*)
Intérieur du four, porte et plâteau avec émail de nettoyage facile.
14
FRANÇAIS
Technical Information
This oven has got a door temperature of below 60 K (as per EN 60335-1/2-6).
MODE
Programming the duration and automatic
stop
1 Press the MODE button until the indicator
above the symbol begins to flash.
2 Select the length of cooking time pressing
the “+” or “-“ buttons.
3 Subsequently, the indicator that was
flashing will remain lit.
4 Press the mode button until the indicator
above the symbol begins to flash.
5 Select the time that cooking should finish
pressing the “+” or “-“ buttons.
6 Subsequently, the indicator that was
flashing will remain lit.
7 Select a function and cooking temperature.
8 The oven will remain disconnected with the
indicators above the and symbols lit.
Your oven is programmed.
9 When the time to begin cooking is reached,
the oven will switch itself on and will
continue cooking during the programmed
time.
10
When the programmed finishing time is
reached, the oven will disconnect, an alarm
will sound and the light above the
symbol will begin to flash.
11
Press any button to switch off the alarm
and the oven will reconnect.
12
Set the controls to the position to
switch of the oven.
Caution
Pressing the MODE button the display on the
screen shows any function programmed. It can
be changed by pressing the “+” or “-“ buttons.
On selecting the desired function, the indicator
above the corresponding signal will light.
In the event of a power cut, all the
programming of the electronic clock will be
erased. The correct time has to be reset and
the watch reprogrammed.
Switching off the clock light
To switch off the clock light, press two buttons
at the same time and, after several seconds
the screen of your clock will go out. To re-light
the clock, press any button and the current
time will reappear.
This function can only be used when the clock
shows the current time and there is no function
programmed (No function symbol is lit).
