Tekmar 519 - Display Symbols; Heat On Status; Mode Off Status; Warning Symbol

© 2014 519_Q - 02/14
2
A Watts Water Technologies Company
3
1
/4”
(83 mm)
Stud
Gang
Box
Thermostat
Front
Thermostat
Base
Adapter Plate 012
4. Installation to Gang Box
5. Wiring
C
518
R Rh W1 S1 Com
No Power
C
519
R Rh W1 S1 Com
No Power
Zone
Valve
24 V
LN
R C
Optional
Slab Sensor 079
Install field
jumper wire
R to Rh
6. User Interface
