Nova 3000 Woodlathe Parts List
Most items are applicable to all countries; items listed with an "Y" are applicable to United States
and Canada; items listed with "Q" are applicable to New Zealand, Australia, UK, Europe, and South Africa.
Item Qty Part No. Description
37 2 BHC08020 Capscrew Button Head
M8 x 20
38 2 FW8 Washer Flat M8 x 16 ZP
39 7 FW12 Washer Flat M12 ZP
1.6 mm Thick
40 1 24008 Lockplate Tailstock
M12 ZP 1.6 mm Thick
42 1 2MTLC Live Center #2MT
44 1 24009 Toolslide Casting
45 1 24048 Cam Nut Toolslide
46 1
BNMZ12090
M12 x 90 Eng Bolt
47 1 K1225 M12 x 25 Allen Head
Flathead Screw
48 1 27002 Plate Toolslide Lock
49 1 24020 Camshaft Toolslide
50 1 24026 Teelock Body
51 2 HP-16 Plughole M16 Black
52 1 24066 Guard Headstock
53Y 1 24054 Flange,
Motor Mount NEMA 56C
53Q 1 24027 Flange, Motor Mount Metric
54 1 24050 Stud M12 x 60 Motor Mount
55 1 24051 Stud M12 x 75 Motor Mount
56 1 24046 Cam Casting for Motor Mount
57 1 24049 Teebar - Motor Mount
58 1 24015 Speed Indicator Label
62 Motor
63Y 1 MPWL Motor Pulley 8 step
5/8 in. Shaft
63Q 1 MPWL19 Motor Pulley 8 step
M19 Shaft
65 1 584J6 Belt Poly Vee
66 1 24055 M5 x 10 Knob (guard cover)
67 5 MP05010 Screw Pan Head Pozi
M5 x 10 ZP
69 1 TR300/1 Toolrest 300 mm with
1 in. DIA post
70Y 1 FP150Y Faceplate 150 mm
with 1-1/4 x 8 TPI
70Q 1 FP150Q Faceplate 150 mm
with M30 x 3.5
71Y 4 KC0608 3/8 x 1 UNC Allen Head
Flathead Screws
71Q 4 CM5010192 M6 x 20 Allen Head
Flathead Screws
Item Qty Part No. Description
1 1 24000 Main Lathe Bed
2 3 NN12 Nut Hex Nyloc M12 ZP
3 1 24023 Detent Pin D12 G/F #19
4 2 24060 Compression Spring
5 1 24088 Detent Pin Handle
6 1 24001 Bed Extension Unit
7 2 24041 Dowel Pin M12 x 36
8 2 24011 Capscrew M12 x 30
9 1 24002 Headstock
10 (Y) 1 24045 Spindle Headstock
1-1/4 x 8 TPI
10
(Q)
1 24024 Spindle Headstock
M30 x 3.5
10 (4) 1 24103 Spindle Headstock
M33 x 3.5
11 1 6306LLB (Rear) NTN 6306 Bearing
11Y 1 6207LLB (Front) SKF 6207-2RSI
Bearing
11Q 1 6306LLB (Front) NTN 6306 Bearing
12 1 EC30 Circlip External 30mm
(1.5 mm wide)
13 1 24080 Wire Form Circlip
14 1 24025 Pulley Headstock
15 1 24061 3/16 in. SQ Key in
M/S x 30 mm
16 1 2MTSPUR Spur Center #2MT
17 1 24062 Spindle Index Knob
18 1 TP131658 Bissel / Tension Pin
3/16 in. x 5/8
19 1 24063 Spindle Index Pin
20 1 DNNO8 M8 Brass Dome Nut
21 2 G0810 Set Screw M8 x 10
Knurled Point
22 2 865913 Ball Knob 3/4 in. DIA
with M6 thread
23 1 25001 TeeLock Arm M10 DIA x 85
with M6 threads
24 1 55048 Headstock Lockpin
25 1 24031 Swivel Pin Headstock
26 1 24039 Tailstock Adjustable Type
27 1 24064 Quill Tailstock 1 in. DIA
with M10 LH thread
28 1 24043 Handwheel, Tailstock
29 1 24087 Operating Bar
30 1 27001 Key Quill Lock
31 1 24019 Quill Lock Knob
32 1 24040 Keeper Plate -
Hardened Steel
33 2 G06010 Set Screw M6 x 10
Knurled Point
34 1 27000 Lock Stud Tailstock
35 2 24016 Lock Arms
36 1 24047 Plate, Adjustable Alignment
26 92-9907-016
