Teknatool nova PRO-TEK SUPERNOVA2 - Using the Safe Lock Woodworm Screw on a Workpiece

19
To use the Safe Lock Woodworm screw on a workpiece
1. Ensure the workpiece surface facing
the jaw segments that is flat as
possible.
2.
Drill an 8mm(.31”)
diameter hole at
approximately 19mm(0.74”)
deep
into the work piece
3.
Firmly press the
Safe Lock
Woodworm screw into the pre
-
drilled hole on the workpiece and
thread the workpiece onto the wood
worm screw until the workpiece
makes good contact with the
mounted jaws on the chucks.
Caution – Maximum capacity and speed of Safe Lock Woodworm screw:
DO NOT USE THE SCREW FOR VERY LARGE WOOD BLANKS. The Safe Lock
Woodworm screw is intended for small bowl and screw chucking work. The maximum
capacity which should be mounted on the screw - 250mm (10 inches) diameter x
100mm (4 inches).
DO NOT EXCEED 600 RPM FOR THIS OPERATION. Use tailstock support whenever
possible.
8mm diameter
Hole. 19mm deep
