Teknatool nova PRO-TEK SUPERNOVA2 - Disassembling the PRO-TEK SUPERNOVA2 Chuck

35
4.
Turn the chuck insert Counter-
clockwise with the 1 ½” spanner to
remove the chuck insert from the
spindle.
Disassembling the PRO-TEK SUPERNOVA
2
chuck
Safety Note:
Remember to wear safety glasses when dealing with circlips as it poses a potential
risk of flying upwards when it slips off from the circlip pliers.
Remove all accessory jaw segments prior to the disassembly process.
The disassembly process can begin with jaw slides being at any position.
Step
No.
Image Description
1.
Remove all the jaw segments
from the chuck.
Note:
Refer to section
“Removing Jaws
from the Chuck”
for instructions
on how to remove the jaws from
the chuck.
