23
The mortis/recess depth should always be slightly shorter than the height of the
mounted jaws.
The dovetail profile on a recess is used to lock
the workpiece on the chuck when the jaws
are expanded to hold the workpiece. This
natural locking action provides significant
level of gripping force.
The workpiece
should never touch
these parts of the
jaws
The workpiece
should only
touch these two
surfaces
