Teknion Leverage - End Trim Installation Procedures

Section:
Description:
Page No:
Date:
END TRIM INSTALLATION (STD WIDTH)
May 2020
4 of 8
TLE_211
END TRIMS & TOP TRIMS
PANEL CONNECTIONS & TRIMS
leverage Installation Guides
STEP 4: Slide Gaskets onto Panel grooves and attach End Trim by pushing it against the Panel side.
B1
B2
Top View Shown.
