Teknion Leverage - Page 5

Tear away part of End Gasket
on the side where Corridor
Width Elements are placed.
Section:
Description:
Page No:
Date:
END TRIM INSTALLATION (CORRIDOR WIDTH)
May 2020
5 of 8
TLE_211
END TRIMS & TOP TRIMS
PANEL CONNECTIONS & TRIMS
leverage Installation Guides
STEP 5: Slide Gaskets onto Panel grooves and attach End Trim by pushing it against the Panel side.
B1
B2
Top View Shown.
