Teknion Leverage - Intermediate End Trim Installation

Section:
Description:
Page No:
Date:
ATTACH CONNECTION CLIP FOR INTERMEDIATE END TRIM (IF APPLICABLE)
May 2020
6 of 8
TLE_211
END TRIMS AND TOP TRIMS
PANEL CONNECTIONS & TRIMS
leverage Installation Guides
STEP 6: Slide Intermediate Connection Clip in to the Top Trim slot, then snap Top Trim onto Panel.
Back View Shown.
A1
C3
A1
C3
