Kona Macro Quick Start Guide T0005158_QS Version 0.3
TEKTELIC Communications Inc. Confidential Page 10 of 14
Figure 6: Firewall Information
12. Verify LoRa traffic:
LoRa operation can be confirmed by using an OTAA sensor and joining with a Network
Server.
▪ Ensure that both Gateway and Sensor is registered on the network server.
▪ Power on the sensor to initiate the join request.
▪ When the Gateway receives an uplink packet (the join request from the Sensor),
the CRC passed and #of received packets fields in KonaFT will increment.
Figure 7: # of received packets and CRC information
