Tektronix 4 Series Quick Start Manual

Figure 4: 4 Series MSO
10.
Aux In auxiliary trigger input connector. A connector to which you can connect an external trigger input signal. Use the Aux In trigger
signal with the Edge trigger mode.
Getting acquainted with your instrument
24
