Specifications
18 AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference
Waveforms
Table 4: Waveforms specifications
Characteristic
Description
Standard
Sine, Square, Pulse, Ramp, and More (Sin(x)/x, Noise, DC, Gaussian, Lorentz,
Exponential Rise, Exponential Decay, and Haversine)
Arbitrary waveform User-defined waveforms; you can edit and save your own waveforms
Waveform length 2 to 131,072
Sampling rate AFG31021, AFG31022 250 MS/s
AFG31051, AFG31052, AFG31101,
AFG31102
Rate changes automatically based on
waveform length:
≤16,000 = 1 GS/s sampling rate
>16,000 = 250 MS/s sampling rate
AFG31151, AFG31152
Rate changes automatically based on
waveform length:
≤16,000 = 2 GS/s sampling rate
>16,000 = 250 MS/s sampling rate
AFG31251, AFG31252
Rate changes automatically based on
waveform length:
≤16,000 = 2 GS/s sampling rate
>16,000 = 250 MS/s sampling rate
Resolution
14 bits
Non-Volatile
Waveform Memory
2380M
Frequency/period
Table 5: Frequency/period specifications
Characteristic
Description
PV reference page
Frequency range
Sine
1
AFG31021, AFG31022
1 µHz to 25 MHz
AFG31051, AFG31052
1 µHz to 50 MHz
AFG31101, AFG31102 1 µHz to 100 MHz
AFG31151, AFG31152 1 µHz to 150 MHz
AFG31251, AFG31252
1 µHz to 250 MHz
Square
2
AFG31021, AFG31022
1 µHz to 20 MHz
AFG31051, AFG31052
1 µHz to 40 MHz
AFG31101, AFG31102
1 µHz to 80 MHz
1
Triggered/gated burst mode: AFG31021, AFG31022: 1 µHz to 12.5 MHz; AFG31051, AFG31052: 1 µHz to 25
MHz; AFG31101, AFG31102: 1 µHz to 50 MHz; AFG31151, AFG31152: 1 µHz to 75 MHz; AFG31251,
AFG31252: 1 µHz to 125 MHz.
2
Triggered/gated burst mode: AFG31021, AFG31022: 1 µHz to 20 MHz; AFG31051, AFG31052: 1 µHz to 40
MHz; AFG31101, AFG31102: 1 µHz to 80 MHz; AFG31151, AFG31152: 1 µHz to 120 MHz; AFG31251,
AFG31252: 1 µHz to 160 MHz.
