Tektronix AFG31000 Series Specification And Performance Verification Technical Reference

Specifications
AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference 21
Characteristic
Description
PV reference page

Accuracy
±(1% of setting +1 mV) at 1 kHz sine waveform,
amplitude >1 mV
pp
, 0 V offset
Amplitude test (on page
40)
Resolution
0.1 mV
pp
, 0.1 mV
rms
, 1 mV, 0.1 dBm or 4 digits
Units
7
V
pp
, V
rms
, dBm, and volt (high level and low level)
Output impedance
50 Ω
Isolation
42 V peak maximum to earth
DC offset
Table 10: DC offset specifications
Characteristic
Description
Range
AFG31021,
AFG31022,
AFG31051,
AFG31052,
AFG31101,
AFG31102
±5 V peak AC + DC into 50 Ω
AFG31151,
AFG31152,
AFG31251,
AFG31252
±2.5 V peak AC + DC into 50 Ω

Accuracy
8
±(1% of |setting| +1 mV + 0.5% of amplitude V
pp
)
Resolution 1 mV
Output impedance 50 Ω
Internal noise add
Table 11: Internal noise add specifications
Characteristic Description
Type
White
Range
0% to 50% of amplitude setting
Resolution
1%
7
dBm is only for sine waveforms. Vrms is not available for arbitrary and noise waveforms.
8
Add 0.5 mV per °C for operation outside of 20 °C to 30 °C.
