Tektronix AFG31000 Series Specification And Performance Verification Technical Reference

Specifications
AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference 19
Characteristic
Description
PV reference page
AFG31151, AFG31152
1 µHz to 120 MHz
AFG31251, AFG31252
1 µHz to 160 MHz
Pulse
AFG31021, AFG31022
1 mHz to 20 MHz
AFG31051, AFG31052
1 mHz to 40 MHz
AFG31101, AFG31102 1 mHz to 80 MHz
AFG31151, AFG31152 1 mHz to 120 MHz
AFG31251, AFG31252
1 mHz to160 MHz
Ramp, Sin(x)/X,
Gaussian, Lorentz,
Exponential Rise,
Exponential Decay,
Haversine
AFG31021, AFG31022
1 µHz to 500 kHz
AFG31051, AFG31052 1 µHz to 800 kHz
AFG31101, AFG31102 1 µHz to 1 MHz
AFG31151, AFG31152 1 µHz to 1.5 MHz
AFG31251, AFG31252
1 µHz to 2.5 MHz
Arbitrary
3
AFG31021, AFG31022
1 mHz to 12.5 MHz
AFG31051, AFG31052
1 mHz to 25 MHz
AFG31101, AFG31102
1 mHz to 50 MHz
AFG31151, AFG31152 1 mHz to 75 MHz
AFG31251, AFG31252 1 mHz to 125 MHz
Noise bandwidth
(–3 dB)
AFG31021, AFG31022,
AFG31051, AFG31052,
AFG31101, AFG31102
150 MHz
AFG31151, AFG31152,
AFG31251, AFG31252
360 MHz
Resolution
1 µHz or 12 digits

Accuracy
±10
–6
setting (except Arbitrary), 0 °C to 50 °C
±10–6 setting±1uHz (ARB) , 0 °C to 50 °C
Frequency/period test
(on page 39)

Stability
4
±1.6 × 10
–6
/year
Accuracy aging
±1.0 × 10
–6
/year
Phase (except DC, noise, and pulse)
Table 6: Phase specifications
Characteristic Description
Range
5
–180° to 180°
3
Triggered/gated burst mode: AFG31021, AFG31022: 1 mHz to 6.25 MHz; AFG31051, AFG31052: 1 mHz to
12.5 MHz; AFG31101, AFG31102: 1 mHz to 25 MHz; AFG31151, AFG31152: 1 mHz to 37.5 MHz; AFG31251,
AFG31252: 1 mHz to 62.5 MHz.
4
Total reference frequency error one year after factory adjustment at any temperature within operating limits.
5
Resolution: 0.01° (sine), 0.1° (other standard waveforms)
