Test records

AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference 57

AC flatness test record: CH 1

AC flatness Minimum Test result Maximum

Frequency 1.00 kHz

(amplitude: 4.0 dB)

_____ dB ( = Reference) _____

Frequency 500 kHz

Reference – 0.20 dB

Reference + 0.20 dB

Frequency 1.00 MHz Reference – 0.20 dB

Reference + 0.20 dB

Frequency 5.00 MHz

Reference – 0.30 dB

Reference + 0.30 dB

Frequency 15.00 MHz

Reference – 0.30 dB

Reference + 0.30 dB

Frequency 25.00 MHz Reference – 0.30 dB

Reference + 0.30 dB

Frequency 50.00 MHz

Reference – 0.30 dB

Reference + 0.30 dB

AC flatness test record: CH 2

AC flatness Minimum Test result Maximum

Frequency 1.00 kHz

(amplitude: 4.0 dB)

_____

dB ( = Reference)

_____

Frequency 500 kHz

Reference – 0.20 dB

Reference + 0.20 dB

Frequency 1.00 MHz

Reference – 0.20 dB

Reference + 0.20 dB

Frequency 5.00 MHz Reference – 0.30 dB

Reference + 0.30 dB

Frequency 15.00 MHz

Reference – 0.30 dB

Reference + 0.30 dB

Frequency 25.00 MHz Reference – 0.30 dB

Reference + 0.30 dB

Frequency 50.00 MHz

Reference – 0.30 dB

Reference + 0.30 dB
