Tektronix AWG5200 Series Installation And Safety Instructions

ReplaceableParts
Item Tektronix part number
Rear panel foot (four per instrument) 348-2037-xx
Screw 211-1481-xx
Front bottom flip-foot (two per instrument) 348-1950-xx
Screw (one per foot) 211-1459-xx
Foot cushion (one per foot) 348-2199-xx
Rear bottom foot (two per instrument) 348-1948-xx
Screw(one per foot) 211-1459-xx
Foot cushion (one per foot) 348-1947-xx
Front handle (two per instrument) 367-0599-xx
Screw (three per handle) 211-1645-xx
Side handle (one per instrument) 367-0603-xx
Spacer (two - one on each end) 407-5992-xx
Top cap (two - one on each end) 407-5991-xx
Screw (two - one on each end) 211-1645-xx
Operating requirements
Place the instrument on a cart or bench, observing clearance requirements:
■
Top and bottom: 0 cm (0 in)
■
Left and right side: 5.08 cm (2 in)
■
Rear: 0 cm (0 in)
CAUTION. To ensure proper cooling, keep sides of the instrument clear of obstructions.
Install the instrument
6 AWG5200 Series Installation and Safety Instructions
