DMM800 Series Performance Verification
14
Handheld Instruments Basic Service
5. Turn the calibrator output off.
6. Disconnect the calibrator from the multimeter.
Perform the following steps to verify the resistance measurement accuracy in 
mode.
1. Set the multimeter dial to ..
2. Connect the calibrator outputs to the multimeter C V   and COM input
connectors.
3. Set the calibrator to each of the values in the  test record and verify that the
multimeter reads within the specified Display minimum and maximum
limits.
4. Turn the calibrator output off.
5. Disconnect the calibrator from the multimeter.
Perform the following steps to verify the resistance measurement accuracy in LV
mode.
1. Set the multimeter dial to ..
2. Push the BLUE button to select the LV mode.
3. Connect the calibrator outputs to the multimeter C V 
 and COM input
connectors.
4. Set the calibrator to each of the values in the Low voltage  test record and
verify that the multimeter reads within the specified Display minimum and
maximum limits.
5. Turn the calibrator output off.
6. Disconnect the calibrator from the multimeter.
Perform the following steps to verify the continuity check accuracy.
1. Set the multimeter dial to
.
2. Connect the calibrator outputs to the multimeter C V 
 and COM input
connectors.
3. Set the calibrator to each of the values in the Continuity test record and
verify proper operation.
4. Turn the calibrator output off.
5. Disconnect the calibrator from the multimeter.
 Check
Low Voltage
 Check
Continuity Check
