Trigger Setup
Trigger Type Trigger Conditions
Runt Trigger on a pulse amplitude that crosses one threshold
but fails to cross a second threshold before recrossing the
first. You can detect positive or negative (or either) runts, or
only those w ider than, less than, greater than, equal to, or
not equal to a specified width. Runt triggers are primarily
used on digital signals.
MSO4000 and DPO4000 Series Oscilloscopes User Manual 141
