Tektronix DPO5000 Series Technical Reference

For Hold time, positive numbers mean a data transition after the clock edge.
Setup + Hold time is the algebraic sum of the Setup Time and Hold Time that you programmed.
Pulse type trigger, minimum pulse,
rearm time, transition time
Pulse class Minimum pulse width Minimum rearm time
Glitch 4 ns 2 ns + 5% of glitch width setting
2 ns + 5% of glitch width setting 4 ns 2 ns
Time-qualified runt 4 ns 8.5 ns + 5% of width setting
Width 4 ns 2 ns + 5% of width upper limit
setting
Slew rate (transition time) 4 ns 8.5 ns + 5% of delta time setting
For the trigger class width and the trigger class runt, the pulse width refers to the width of the pulse
being measured. The rearm time refers to the time between pulses.
For trigger class runt, pulse width refers to the width of the pulse being measured. Rearm time
refers to the time between pulses.
For the trigger class slew rate, the pulse width refers to the delta time being measured. The rearm
time refers to the time it takes the signal to cross the two trigger thresholds again.
Transition time trigger, delta time
range
4 ns to 8 s
Time range for glitch, width,
timeout, or time-qualified runt
4 ns to 8 s
Time accuracy for glitch, timeout,
or width triggering
Time Range Accuracy
1 ns to 500 ns ±(20% of setting + 0.5 ns)
520 ns to 1 s ±(0.01% of setting + 100 ns)
B trigger after events, minimum
pulse width and maximum event
frequency, typical
4 ns, 500 MHz
B trigger, minimum time between
arm and trigger, typical
4 ns
For trigger after time, this is the time between the end of the time period and the B trigger event.
For trigger after events, this is the time between the last A trigger event and the first B trigger event.
B trigger after time, time range 4 ns to 8 seconds
B trigger after events, event range 1 to 4,000,000 events
Trigger level ranges
Source Range
Any input channel ±8 divisions from center of screen
±8 divisions from 0 V when vertical LF
reject trigger coupling is selected
Aux In (External) ±8 V
Line Not applicable
Trigger specifications (cont.) Specifications (MSO/DPO5000/B Series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 91
